Content

Tex
 Tex Symbol
  Miscellaneous Symbols
   Example
  Miscellaneous Accents
   Example

Tex

For TextMobject object, the input is plain text therefore Latex letters and symbols are denoted by a $⋯$ pair. But for TexMobject object, the input is Latex code and plain text is entered as Latex code \text{⋯}.

Tex Symbol

Miscellaneous Symbols

Å\AA \angle \backprime \\backslash
\bigcap \bigcup \bigodot \bigoplus
\bigotimes \bigstar \biguplus \bigvee
\bigwedge \blacksquare \blacktriangle \blacktriangledown
\cdots \checkmark ®\circledR \circledS
\clubsuit \complement \coprod ©\copyright
\ddots \diamondsuit \downarrow \Downarrow
\ell \emptyset ð\eth \exists
\Finv \flat \forall \Game
ħ\hbar \heartsuit \hslash \ldots
\iiiint \iiint \iint ℑ(𝕀) \Im
ı\imath \infty \int ȷ\jmath
\langle \lceil \lfloor \llcorner
\lrcorner \measuredangle \nabla \natural
\neg \oiint \oint \P
\partial \prime \prod \rangle
\rceil ℜ(ℝ) \Re \rfloor §\S
\sharp \spadesuit \sphericalangle \square
ß\ss \sum \surd \triangle
\triangledown \ulcorner \uparrow \Uparrow
\urcorner \varnothing \vartriangle \vdots
|\vert \Vert \wp ¥\yen

Example

Code
# folder/file: tut/manim_useful_textmobject_misc_001a.py
from manimlib.scene.scene import Scene
from manimlib.mobject.svg.tex_mobject import TexMobject, TextMobject

class manim_useful_textmobject_misc_001a(Scene):

   def construct(self):
      text="\\AA\\angle\\backprime\\backslash\\bigcap\\bigcup\\bigodot\\bigoplus\\bigotimes\\bigstar\\biguplus\\bigvee\\cr\\bigwedge\\blacksquare\\blacktriangle\\blacktriangledown\\cdots\\checkmark\\circledR\\circledS\\clubsuit\\complement\\coprod\\copyright\\ddots\\cr\\diamondsuit\\downarrow\\Downarrow\\ell\\emptyset\\eth\\exists\\Finv\\flat\\forall\\Game\\hbar\\heartsuit\\hslash\\ldots\\iiiint\\iiint\\iint\\cr\\Im\\imath\\infty\\int\\jmath\\langle\\lceil\\lfloor\\llcorner\\lrcorner\\measuredangle\\nabla\\natural\\neg\\oiint\\oint\\cr\\P\\partial\\prime\\prod\\rangle\\rceil\\Re\\rfloor\\S\\sharp\\spadesuit\\sphericalangle\\square\\ss\\sum\\surd\\triangle\\triangledown\\ulcorner\\cr\\uparrow\\Uparrow\\urcorner\\varnothing\\vartriangle\\vdots\\vert\\Vert\\wp\\yen"
      self.add(TexMobject("%s" %text.replace("\\","\\backslash ").replace("\\backslash cr","\cr")).shift([0,2,0]).scale(0.4))
      self.add(TexMobject("%s" %text).shift([0,-2,0]).scale(0.4))
Output

Miscellaneous Accents

 \textacutemacron a  \textacutemacron A  \textacutewedge a  \textacutewedge A
 \textadvancing a  \textadvancing A  \textbottomtiebar a  \textbottomtiebar A
 \textbrevemacron a  \textbrevemacron A  \textcircumacute a  \textcircumacute A
 \textcircumdot a  \textcircumdot A  \textdotacute a  \textdotacute A
 \textdotbreve a  \textdotbreve A  \textdoublegrave a  \textdoublegrave A
 \textdoublevbaraccent a  \textdoublevbaraccent A  \textfallrise a  \textfallrise A
 \textgravecircum a  \textgravecircum A  \textgravedot a  \textgravedot A
 \textgravemacron a  \textgravemacron A  \textgravemid a  \textgravemid A
 \texthighrise a  \texthighrise A  \textinvsubbridge a  \textinvsubbridge A
 \textlowering a  \textlowering A  \textlowrise a  \textlowrise A
 \textmidacute a  \textmidacute A  \textovercross a  \textovercross A
 \textoverw a  \textoverw A  \textpolhook a  \textpolhook A
 \textraising a  \textraising A  \textretracting a  \textretracting A
 \textringmacron a  \textringmacron A  \textrisefall a  \textrisefall A
 \textroundcap a  \textroundcap A  \textseagull a  \textseagull A
 \textsubacute a  \textsubacute A  \textsubarch a  \textsubarch A
 \textsubbar a  \textsubbar A  \textsubbridge a  \textsubbridge A
 \textsubcircum a  \textsubcircum A  \textsubdot a  \textsubdot A
 \textsubgrave a  \textsubgrave A  \textsublhalfring a  \textsublhalfring A
 \textsubplus a  \textsubplus A  \textsubrhalfring a  \textsubrhalfring A
 \textsubring a  \textsubring A  \textsubsquare a  \textsubsquare A
 \textsubtilde a  \textsubtilde A  \textsubumlaut a  \textsubumlaut A
 \textsubw a  \textsubw A  \textsubwedge a  \textsubwedge A
 \textsuperimposetilde a  \textsuperimposetilde A  \textsyllabic a  \textsyllabic A
 \texttildedot a  \texttildedot A  \texttoptiebar a  \texttoptiebar A
 \textvbaraccent a  \textvbaraccent A

Example

Code
# folder/file: tut/manim_useful_textmobject_misc_002a.py
from manimlib.scene.scene import Scene
from manimlib.mobject.svg.tex_mobject import TexMobject, TextMobject

class manim_useful_textmobject_misc_002a(Scene):

   def construct(self):
      text="\\textacutemacron a\\textacutemacron A\\textacutewedge a\\textacutewedge A\\textadvancing a\\textadvancing A\\textbottomtiebar a\\textbottomtiebar A\\cr\\textbrevemacron a\\textbrevemacron A\\textcircumacute a\\textcircumacute A\\textcircumdot a\\textcircumdot A\\textdotacute a\\textdotacute A\\cr\\textdotbreve a\\textdotbreve A\\textdoublegrave a\\textdoublegrave A\\textdoublevbaraccent a\\textdoublevbaraccent A\\textfallrise a\\textfallrise A\\cr\\textgravecircum a\\textgravecircum A\\textgravedot a\\textgravedot A\\textgravemacron a\\textgravemacron A\\textgravemid a\\textgravemid A\\cr\\texthighrise a\\texthighrise A\\textinvsubbridge a\\textinvsubbridge A\\textlowering a\\textlowering A\\textlowrise a\\textlowrise A\\textmidacute a\\cr\\textmidacute A\\textovercross a\\textovercross A\\textoverw a\\textoverw A\\textpolhook a\\textpolhook A\\textraising a\\textraising A\\textretracting a\\cr\\textretracting A\\textringmacron a\\textringmacron A\\textrisefall a\\textrisefall A\\textroundcap a\\textroundcap A\\textseagull a\\textseagull A\\cr\\textsubacute a\\textsubacute A\\textsubarch a\\textsubarch A\\textsubbar a\\textsubbar A\\textsubbridge a\\textsubbridge A\\textsubcircum a\\textsubcircum A\\cr\\textsubdot a\\textsubdot A\\textsubgrave a\\textsubgrave A\\textsublhalfring a\\textsublhalfring A\\textsubplus a\\textsubplus A\\textsubrhalfring a\\cr\\textsubrhalfring A\\textsubring a\\textsubring A\\textsubsquare a\\textsubsquare A\\textsubtilde a\\textsubtilde A\\textsubumlaut a\\textsubumlaut A\\cr\\textsubw a\\textsubw A\\textsubwedge a\\textsubwedge A\\textsuperimposetilde a\\textsuperimposetilde A\\textsyllabic a\\textsyllabic A\\cr\\texttildedot a\\texttildedot A\\texttoptiebar a\\texttoptiebar A\\textvbaraccent a\\textvbaraccent A"
      self.add(TexMobject("%s" %text.replace("\\","\\backslash ").replace("\\backslash cr","\cr").replace(" a","\\ a").replace(" A","\\ A")).shift([0,2,0]).scale(0.4))
      self.add(TexMobject("%s" %text).shift([0,-1.75,0]).scale(0.4))
Output
