Specifications4TB2TB1TB500GB Standard ModelZP4000GM30013ZP2000GM30013ZP1000GM30013ZP500GM30013 Heatsink ModelZP4000GM30023ZP2000GM30023ZP1000GM30023ZP500GM30023 InterfacePCIe Gen4 ×4 NVMe 1.4PCIe Gen4 ×4 NVMe 1.4PCIe Gen4 ×4 NVMe 1.4PCIe Gen4 ×4 NVMe 1.4 NAND Flash Memory3D TLC3D TLC3D TLC3D TLC Form FactorM.2 2280-D2M.2 2280-D2M.2 2280-S2M.2 2280-S2 Performance Sequential Read (Max, MB/s), 128KB7300730073007000 Sequential Write (Max, MB/s), 128KB6900690060003000 Random Read (Max, IOPS), 4KB QD32T81,000,0001,000,000800,000400,000 Random Write (Max, IOPS), 4KB QD32T81,000,0001,000,0001,000,000700,000 Endurance/Reliability Total Bytes Written (TB)510025501275640 Mean Time Between Failures (MTBF, hours)1,800,0001,800,0001,800,0001,800,000 Rescue Data Recovery Services(years)3333 Warranty, Limited (years)5555 Power Management Active Power, Average (W)8.48.06.55.8 Idle Power PS3, Average (mW)25241614 Low Power L1.2 mode (mW)<5<5<5<5 Environmental Temperature, Operating Internal (°C)0°C – 70°C0°C – 70°C0°C – 70°C0°C – 70°C Temperature, Nonoperating (°C)-40°C – 85°C-40°C – 85°C-40°C – 85°C-40°C – 85°C Shock, Nonoperating: 0.5ms (Gs)1500150015001500 Special Features TRIMYesYesYesYes S.M.A.R.T.YesYesYesYes Halogen FreeYesYesYesYes RoHS ComplianceYesYesYesYes Physical Length (mm/in, max)80.15mm/3.156in80.15mm/3.156in80.15mm/3.156in80.15mm/3.156in Length with heatsing(mm, max)24.50mm24.50mm24.50mm24.50mm Width (mm/in, max)22.15mm/0.872in22.15mm/0.872in22.15mm/0.866in22.15mm/0.872in Height (mm/in, max)3.58mm/0.141in3.58mm/0.141in2.23mm/0.088in2.23mm/0.088in Height with heatsink(mm, max)11.04mm11.04mm11.04mm11.04mm Weight (g/lb)10.6g/0.023lb10.0g/0.022lb8.1g/0.017lb7.7g/0.016lb Weight with heatsink(g/lb)47g (max)47g (max)47g (max)47g (max)

About Heatsink SSDs

• Heatsinks are pre-installed. Do not remove the heatsink; you can damage the SSD.
• Dimensions exceed standard size specifications for the M.2 without a heatsink. Please verify that the system has enough space for installation.
• SSDs with heatsinks are recommended for M.2 with connectors H3.2 and above.
