Geometry Curved Shape
 Class AnnularSector(Arc)
  Example
 Class Sector(AnnularSector)
  Example
 Class Circle(Arc)
  Example
 Class Ellipse(Circle)
  Example
 Class Annulus(Circle)
  Example
 Class Dot(Circle)
  Example
 Class SmallDot(Dot)
  Example

Geometry Curved Shape

The defined geometry VMobject related to curved line in geometry.py
  • Class AnnularSector(Arc)
  • Class Sector(AnnularSector)
  • Class Circle(Arc)
  • Class Ellipse(Circle)
  • Class Annulus(Circle)
  • Class Dot(Circle)
  • Class SmallDot(Dot)

Class AnnularSector(Arc)

AnnularSector is used to generate an annular sector for given outer_radius, inner_radius.

Example

Code
# folder/file: tut/manim_mobject_annularsector_001a.py

from manimlib.scene.scene import Scene
from manimlib.mobject.geometry import AnnularSector
from manimlib.animation.creation import ShowCreation

class manim_mobject_annularsector_001a(Scene):
   def construct(self):
      poly = AnnularSector(outer_radius=1.1,inner_radius=0.5
      ,arc_center=(0,-2,0),start_angle=0.25,angle=1.3208,color="#33FF33",fill_color="#FFFF00",fill_opacity=1)
      self.play(ShowCreation(poly),run_time=2)
      self.play(ShowCreation(AnnularSector(arc_center=(0,0,0),start_angle=1.5708,stroke_width=50,color="#33FF33",fill_color="#FFFF00",fill_opacity=1)),run_time=2)
      self.play(ShowCreation(AnnularSector()),run_time=2)
      self.play(ShowCreation(AnnularSector(start_angle=3.1416,angle=1.5708,arc_center=(-2,1,0),stroke_width=15)),run_time=2)
Output

Class Sector(AnnularSector)

Sector is used to generate an annular sector for given outer_radius.

Example

Code
# folder/file: tut/manim_mobject_sector_001a.py

from manimlib.scene.scene import Scene
from manimlib.mobject.geometry import Sector
from manimlib.animation.creation import ShowCreation

class manim_mobject_sector_001a(Scene):
   def construct(self):
      poly = Sector(outer_radius=1.1,inner_radius=0.5
      ,arc_center=(0,-2,0),start_angle=0.25,angle=1.3208,color="#33FF33",fill_color="#FFFF00",fill_opacity=1)
      self.play(ShowCreation(poly),run_time=2)
      self.play(ShowCreation(Sector(arc_center=(0,0,0),start_angle=1.5708,stroke_width=50,color="#33FF33",fill_color="#FFFF00",fill_opacity=1)),run_time=2)
      self.play(ShowCreation(Sector()),run_time=2)
      self.play(ShowCreation(Sector(start_angle=3.1416,angle=1.5708,arc_center=(-2,1,0),stroke_width=15)),run_time=2)
Output

Class Circle(Arc)

Circle is used to generate a circle for given arc_center, and radius.

Example

Code
# folder/file: tut/manim_mobject_circle_001a.py

from manimlib.scene.scene import Scene
from manimlib.mobject.geometry import Circle
from manimlib.animation.creation import ShowCreation

class manim_mobject_circle_001a(Scene):
   def construct(self):
      poly = Circle(radius=1.1,arc_center=(0,0,0),color="#33FF33",fill_color="#FFFF00",fill_opacity=1)
      self.play(ShowCreation(poly),run_time=2)
      self.play(ShowCreation(Circle(arc_center=(1,1,0),stroke_width=50,fill_color="#FFFF00",fill_opacity=1)),run_time=2)
      self.play(ShowCreation(Circle()),run_time=2)
      self.play(ShowCreation(Circle(arc_center=(-3,2,0),stroke_width=15)),run_time=2)
Output

Class Ellipse(Circle)

Ellipse is used to generate an ellipse for given width, and height.

Example

Code
# folder/file: tut/manim_mobject_ellipse_001a.py

from manimlib.scene.scene import Scene
from manimlib.mobject.geometry import Ellipse
from manimlib.animation.creation import ShowCreation

class manim_mobject_ellipse_001a(Scene):
   def construct(self):
      poly = Ellipse(width=5,height=2,arc_center=(0,0,0),color="#33FF33",fill_color="#FFFF00",fill_opacity=1)
      self.play(ShowCreation(poly),run_time=2)
      self.play(ShowCreation(Ellipse(width=2,height=5,arc_center=(1,1,0),stroke_width=50,fill_color="#FFFF00",fill_opacity=1)),run_time=2)
      self.play(ShowCreation(Ellipse()),run_time=2)
      self.play(ShowCreation(Ellipse(arc_center=(-3,2,0),stroke_width=15)),run_time=2)
Output

Class Annulus(Circle)

Annulus is used to generate an annulus for given outer_radius, inner_radius.

Example

Code
# folder/file: tut/manim_mobject_annulus_001a.py

from manimlib.scene.scene import Scene
from manimlib.mobject.geometry import Annulus
from manimlib.animation.creation import ShowCreation

class manim_mobject_annulus_001a(Scene):
   def construct(self):
      poly = Annulus(outer_radius=2.1,arc_center=(-3,0,0),color="#33FF33",fill_color="#FFFF00",fill_opacity=1)
      self.play(ShowCreation(poly),run_time=2)
      self.play(ShowCreation(Annulus(arc_center=(2,2,0),stroke_width=50,fill_color="#FFFF00",fill_opacity=1)),run_time=2)
      self.play(ShowCreation(Annulus()),run_time=2)
      self.play(ShowCreation(Annulus(arc_center=(-3,2,0),color="#33FF33",fill_color="#FFFF00",stroke_width=15)),run_time=2)
Output

Class Dot(Circle)

Dot is used to generate a dot for given radius, and color.

Example

Code
# folder/file: tut/manim_mobject_dot_001a.py

from manimlib.scene.scene import Scene
from manimlib.mobject.geometry import Dot
from manimlib.animation.creation import ShowCreation

class manim_mobject_dot_001a(Scene):
   def construct(self):
      poly = Dot(radius=2.1,color="#33FF33",fill_color="#FFFF00",fill_opacity=1)
      self.play(ShowCreation(poly),run_time=2)
      self.play(ShowCreation(Dot(stroke_width=150,fill_color="#FF8800",fill_opacity=1).shift([3,0,0])),run_time=2)
      self.play(ShowCreation(Dot().shift([2.5,2.5,0])),run_time=2)
      self.play(ShowCreation(Dot(radius=1.5,stroke_width=15,fill_color="#FF8800",fill_opacity=1).shift([-3,0,0])),run_time=2)
Output

Class SmallDot(Dot)

SmallDot is usually used to generate a small dot for given color

Example

Code
# folder/file: tut/manim_mobject_smalldot_001a.py

from manimlib.scene.scene import Scene
from manimlib.mobject.geometry import SmallDot
from manimlib.animation.creation import ShowCreation

class manim_mobject_smalldot_001a(Scene):
   def construct(self):
      poly = SmallDot(radius=2.1,color="#33FF33",fill_color="#FFFF00",fill_opacity=1)
      self.play(ShowCreation(poly),run_time=2)
      self.play(ShowCreation(SmallDot(stroke_width=150,fill_color="#FF8800",fill_opacity=1).shift([3,0,0])),run_time=2)
      self.play(ShowCreation(SmallDot().shift([2.5,2.5,0])),run_time=2)
      self.play(ShowCreation(SmallDot(radius=1.5,stroke_width=15,fill_color="#FF8800",fill_opacity=1).shift([-3,0,0])),run_time=2)
Output
